Additional Information:
Product Details:
| Model | HJ1-0.7/1.0 | HJ2-1.0/1.25 | HJ4-1.0/1.25 | HJ6-1.25/1.6 | HJ8-1.25/1.6 |
| Rated evaporation capacity (t/h) | 1 | 2 | 4 | 6 | 8 |
| Rated steam pressure (Mpa) | 0.7/1.0 | 1.0/1.25 | 1.0/1.25 | 1.25/1.6 | 1.25/1.6 |
| Thermal efficiency (％) | >90 | >90.2 | >91 | >91.5 | >91.6 |
| Fuel consumption Light oil (Kg/h) | 66.5 | 133 | 266 | 399 | 532 |
| Fuel consumption Natural gas (Nm³/h) | 75 | 150 | 300 | 450 | 600 |
| Overall dimension (m) | 3.6×2.0×2.0 | 4.8×2.5×2.46 | 5.8×2.85×2.8 | 7.25×3.1×3.15 | 7.45×3.26×3.2 |
| Weight (t) | 4 | 8 | 13 | 19 | 22.6 |
| Body Heating Area (m2) | 25 | 60 | 113 | 181 | 190 |
| Note: Parameter is for reference only, we can design the boilers based on customers’ needs. | |||||
Oil/Gas Steam Boilers Application:
Due to its compact structure, safe operation, easy installation, low pollution, and low noise, our oil and gas boilers are widely used in industrial production and processing such as textile factories, pharmaceutical industries, food and beverage industries, and chemical industries. Industry, clothing industry, food processing industry, wood processing industry, can also be used for centralized heating in enterprises, hotels, hospitals, and civil buildings.
Oil/Gas Steam Boilers Advantages
1. High Efficiency
1) Equipped with high quality and reliable burner, high combustion efficiency, low harmful gas emission, and noiseless operation.
2) Adopts horizontal type three pass structure, absorbs the thermal expansion effectively. Uses a large diameter corrugated furnace. Large combustion space, high combustion efficiency.
3) The spirally corrugated tube strengthens the disturbance of flue gas, high heat transfer efficiency.
4) The boiler shell uses an aluminum silicate board for heat preservation, high thermal shielding efficiency, low heat loss, which increases the boiler thermal efficiency.
5) Equipped with economizer, make full use of the heat of flue gas, decrease the exhaust smoke temperature, the thermal efficiency could be increased to as high as 98%.
2. High Safety Performance
1) Complete gas manifolds and protection system, including filter, pressure regulating valve, and solenoid valve, etc., to ensure the safety performance of the fuel.
2) Reliable boiler auxiliaries and multiple safety protection devices, such as pressure controller, pressure transmitter, water level alarm, safety valve, etc.
3) Adopts PLC full automatic intelligent control cabinet and interlock protection program, has the protection function of water shortage, overpressure, over-temperature, gas leakage, flame out, electric leakage, and phrase-lacking or overloading of motor, etc.
4) Equipped with explosion-proof equipment, discharge high energy when deflagration happened in the furnace, to ensure the boiler operates safely and efficiently.
3. Low Cost
4. Save Space
Adopts fast assemble structure, compact structure, convenient for transportation, small occupation.
5. Convenient Maintenance
1) There are manhole, head hole, and special hand hole on the boiler. The front and back smoke chambers are equipped with movable doors, convenient for boiler internal installation, inspection, and cleaning.
2) The explosion-proof door has the fire sight glass and inspection gallery, convenient for furnace checking and maintaining.
