This small rice grain dryer is mainly used to dry grain paddy in parboiled rice mill plants. The design of this rice mill dryer is a two-level spiral quick delivery.
This small rice grain dryer is mainly used to dry grain paddy in parboiled rice mill plants. The design of this rice mill dryer is a two-level spiral quick delivery. The first level delivers the materials quickly into the barrel, and the second level continuously rapidly lifts the raw material to the upper of the barrel and then throws the raw material with deliquescence scattered, while the hot air from the center of the barrel bottom is blown out all around.
1. Synchronization of mixing and drying: As the material continues to flow during the drying process, the heat penetration is uniform, the drying time is short and it is not easy to knot;
2. The standard model of this series is a double-layer barrel design (economical design is a single-layer design), the inner layer is made of stainless steel material for the material contact part; the middle inter-layer installation and special insulation materials, so it can achieve safety and energy saving effect;
3. Special high-frequency heater, fast heating, and low power consumption
4. A special double-pipe moisture discharge port can effectively discharge moisture and collect dust without polluting the working environment;
5. Two-in-one dry mixing function, when drying is not required, just turn off the “heating switch” and “fan switch”, this series of models can be used for plastic mixing and homogenization purposes, one machine and two uses.
| Model | Capacity(kg) | Power(kW) | Heating Power(kW) | Speed(r/min) | Size(mm) |
| HJ500 | 500 | 3 | 12 | 350 | Ø1200*2350 |
| HJ1000 | 1000 | 4 | 20 | 350 | Ø1600*2650 |
| HJ1500 | 1500 | 4 | 20 | 350 | Ø1700*3150 |
| HJ2000 | 2000 | 5.5 | 30 | 350 | Ø1750*3150 |
| HJ3000 | 3000 | 7.5 | 40 | 350 | Ø2200*3850 |
| HJ5000 | 5000 | 11 | 50 | 350 | Ø2400*4350 |
