The HZZD Rotary Combined Multi-Deck Screen is a highly efficient cleaning and grading machine, specially designed for the precise separation of big and small impurities from granular materials. With its rotary motion and multi-deck structure, this equipment delivers stable performance, high throughput, and reliable results, making it an essential choice for modern production lines.
This machine effectively removes oversized particles, fine dust, and other impurities, ensuring cleaner raw materials and more consistent product quality. Its multi-deck design allows for simultaneous separation into different size fractions, greatly improving processing efficiency.
With its advanced screening technology and versatile applications, the HZZD Rotary Combined Multi-Deck Screen provides global customers with reliable solutions for cleaner, higher-quality materials and optimized production processes.
The HZZD Rotary Combined Multi-Deck Screen is suitable for a broad range of industries, including:
1. Grain Processing: Cleaning and classifying rice, wheat, corn, and other cereals.
2. Feed Industry: Ensuring raw feed materials are free from contaminants before further processing.
3. Food Industry: Screening sugar, flour, starch, and other food ingredients with high precision.
4. Chemical Industry: Grading powders, granules, and additives for improved consistency.
5. Brewing Industry: Removing impurities from malt, barley, and other brewing materials to ensure product purity.
1. Multi-functional combination design with four sets of eight-layer screen surfaces, enabling simultaneous cleaning of materials (large and medium impurities, small impurities). Large effective screening area ensures high capacity and excellent cleaning and grading performance.
2. Equipped with an integrated air suction separation and dust-settling discharge system, effectively removing light impurities and dust (with external air suction) and discharging them outside the machine in real time.
3. Feeding system includes a multi-channel distributor and vibrating pressure gate, ensuring uniform material distribution across all screen layers for optimal cleaning and grading efficiency.
4. Screen body suspended by a combination of hanging rods for stable operation, minimizing vibration impact on floors and structures.
5. Metal screen frames with reduced thickness yet high strength and rigidity; flat screen surfaces; convenient and simple installation/removal; excellent interchangeability.
6. Fitted with a brake motor for safe and reliable operation, with minimal idle running time.
7. Low energy consumption—approximately 0.031 kW per ton of grain processed.
| Model | HZZD150*200/8 | HZZD200*200/8 |
| Capacity(t/h) | 120-140 | 150-180 |
| Ratary Speed(r/min) | 300±5 | 300±5 |
| Power(kw) | 3+0.75+0.04*2 | 4+0.75+0.04*2 |
| Weight(kg) | 6100 | 7100 |
| Dimension(mm) | 3462*2445*3892 | 3462*2945*3892 |
